suit dry cleaning machine environment friendly for railway company GOWORLD
Machine Type:
Hotel clothes dry cleaner model:TC-4
Place of Origin:
Guangdong,China
Lead Time:
25-30working days after TT2 deposit
Suitable For:
Laundry shop,commercial laundromat,fire brigade,hotel
Machine Voltage:
380V,220V
Heat Way:
Electric heating,steam heating
Solvent:
Perchloroethylene
Product Details
GOWORLD LAUNDRY EQUIPMENT's laundry machine is of excellent quality, which is reflected in the details. laundry machine is in line with the stringent quality standards. The price is more favorable than other products in the industry and the cost performance is relatively high.
Enterprise Strength
- GOWORLD LAUNDRY EQUIPMENT always gives priority to customers and services. We continuously provide excellent services for numerous customers.
1. GOWORLD suit dry cleaning machine is designed and fabricated using unmatched quality raw materials and latest technology as per the international quality criterion.
2. Compared with other products, the product has obvious superiority such as long service life, stable performance, and good usability.
3. This product manifests its huge potential in the field of application.
Product Specifications
GOWORLD
| Model | Unit | TC4020S/E | TC4025S/E | TC4028S/E | TC4032S/E | TC4036S/E | TC4040S/E | |
| Washing Capacity | kg | 10 | 12 | 14 | 16 | 18 | 20 | |
| Cylinder Capacity | L | 160 | 200 | 240 | 280 | 320 | 360 | |
| Washing Rotation Speed | r/min | 34 | 34 | 34 | 34 | 34 | 34 | |
| Extract Speed | r/min | 370 | 370 | 370 | 370 | 370 | 370 | |
| Base Tank | #1 | L | 112 | 112 | 129 | 164 | 164 | 164 |
| #2 | L | 127 | 127 | 147 | 177 | 177 | 177 | |
| Capacity | #3 | L | 112 | 112 | 129 | 180 | 180 | 180 |
| Still Tank Capacity | L | 150 | 150 | 150 | 205 | 205 | 205 | |
| Filter Area | m2 | 2.8 | 3 | 3 | 3 | 3 | 3 | |
| Total Motor Power | kw | 4 | 4.5 | 4.5 | 6 | 6 | 6 | |
| Electric | Still | kw | 6 | 6 | 6 | 6 | 6 | 6 |
| Heated Power | Drying | kw | 6.75 | 6.75 | 6.75 | 8.1 | 8.1 | 8.1 |
| Maximum Steam | kg/h | 32 | 34 | 36 | 40 | 42 | 44 | |
| Consumption | ||||||||
| Maximum Water Consumption | kg/h | 450 | 500 | 550 | 580 | 600 | 620 | |
| External Size | Width | mm | 1690 | 1690 | 1690 | 1940 | 1940 | 1940 |
| Thickness | mm | 1450 | 1450 | 1450 | 1450 | 1450 | 1450 | |
| Height | mm | 2040 | 2040 | 2040 | 2200 | 2200 | 2200 | |
| Weight | kg | 850 | 900 | 950 | 1100 | 1150 | 1200 | |
| Remark | 1.S－ Steam type E－ Electric type | |||||||
| 2.Steam Pressure：4-6KG/CM2; Cooling Water Pressure：1.5-2kg/cm2 | ||||||||
| 3.Power Source：380V/3P/50HZ | ||||||||
Workshop Products
◆ Lots of recruitment of nylon filter.
◆ Full-closed refrigerated recovery system.
◆ Solvent: Polyethylene.can be cycle to use.
◆ Electric or steam heating can be choose by customer.
◆ Three kinds of solvent tanks to meet demand for colored clothes.
Product Details
10kg-20kg hotel clothes dry cleaner environment friendly full closed machine is through the collection of the organic solvents,filtered,and the condensate recovery when dry cleaning,implements the dry cleaning solution recycling,save the cost of solvent and has reached the requirement of environmental protection,have the characteristics of carbon basket system and full-closed refrigerated recovery system,no need to add diatom,so it’s no pollution to the air, no harm to human, keep the room fresh.it’s especially suitable for hotel,laundry shop,textile industries,fire brigade etc.
NO.1 / 10kg-20kg hotel clothes dry cleaner full closed door lock system
Full-closed door lock system,Pneumatically controlled door lock switch, the outside can not be opened during work operation, preventing dry cleaning oil leakage.
NO.2 / 10kg-20kg hotel clothes dry cleaner button trap
Button trap,Stainless steel component parts to ensure stable running .The working solvent is coarsely filtered to remove impurities such as buttons and coins that are dropped during the washing process.
NO.3 / 10kg-20kg hotel clothes dry cleaner lint trap
Lint trap,The door is equipped with a safety switch,When the door is opened, the computer alarms, the machine is self-locking and cannot work.
NO.4 / 10kg-20kg hotel clothes dry cleaner consists systems
Hotel clothes dry cleaner consists systems:washing system,filtration system,distillation system,drying and recycling system,solvent storage tank,pump,lint trap and button trap.
PACKING & SHIPPING
We support both OEM & ODM packaging. Our normally delivery method are by the sea, by air, by international express (DHL, UPS, TNT, FedEx)
Company Features
1. With abundant R&D and production experience, FOSHAN GOWORLD LAUNDRY EQUIPMENT CO., LTD stands out in the field of dry cleaning equipment .
2. The globally advanced development procedure and strong technical base makes FOSHAN GOWORLD LAUNDRY EQUIPMENT CO., LTD highly popular.
3. GOWORLD values the work that can add value for customers. Contact! FOSHAN GOWORLD LAUNDRY EQUIPMENT CO., LTD will tap into the our whole strength to provide you with the best. Contact! GOWORLD adheres to excellent quality and professional service. Contact! FOSHAN GOWORLD LAUNDRY EQUIPMENT CO., LTD always meets the real needs of each customer and aims to produce the perfect dry cleaning washing machine. Contact!
