manual barrier washer extractor unit easy use for laundry plants

Machine Type:
Simple installation
Place of Origin:
Guangdong,China(Mainland)
Heat source:
Steam or electric heating
Certificate:
CE & ISO &SGS passed
Lead Time:
20-25working days after TT deposit
Steam Inlet:
1/2”,Air outlet:3/2”,Drain outlet:75mm-80mm
Suitable For:
Hotel laundry,hospital laundry,restaurants laundry,railway company laundry,textile industries laundry,fire brigade laundry,sanitary laundry engineering,food laundry engineering,etc.
Capacity:
From 15kg,25kg,35kg,50kg,80kg,100kg,120kg,to 150kg meet different laundry need
Inquiry



Product Specifications


Mode
XGQ-150FXGQ-120FXGQ-100FXGQ-80FXGQ-50F(FD)XGQ-35F(FD)XGQ-25F(FD)XGQ-15F(FD)
Capacitykg1501201008050352515
Drum size(Φ×L)mmΦ1320×1100Φ1220×1030Φ1220×860Φ1220×690Φ955×700Φ955×490Φ750×540Φ750×340
Washing speedr/min3233333336363838
Extract speedr/min660670670670750750850850
Motor power/ Heat powerkw2218.515117.5/365.5/273/212.2/15
Weightkg4100350031502850170015001000700
External SizeLengthmm19501850185018501440144012201220
Widthmm21202040184016701530135012701140
Heightmm20302030170017001540154020302060


Workshop Products


manual barrier washer extractor unit easy use for laundry plants 11
manual barrier washer extractor unit easy use for laundry plants 12
  •  Japanese V-belts, run smoothly.

  •  Delta inverter.

  •  Frequency controlled motor.

  •  Japanese bearings.

  •  Europe Schneider electric parts. safety and reliable.

  •  #304 Stainless steel cabinet and drum.

  •  Imported Japanese seal makes no leakage.

  •  USB port microprocessor enables to reprogram freely&easily by PC.

  •  Easy access to all parts for maintenance.

  •  Large drain valves.

  •  Each drum tested by dynamic balance machine.

  •  Manual or automatic detergent supply system can be order to choose.

  •  Electric heating ,steam heating can be order to choose.

Products Details


manual barrier washer extractor unit easy use for laundry plants 13

The 15kg-150kg automatic soft mount washer extractor is a series of laundry equipment under the GOWORLD brand.It has the characteristics of suspension structure and long-term continuous operation,The whole washer extractor tank system is installed suspended on the spring and damping devices,when the machine washer and water extracting, shock absorption is up to 95%,and without foundation required when using, it’s especially suitable for hotel laundry equipment,hospital laundry equipment,restaurants laundry equipment, and railway company laundry equipment etc. The use of high-powered motor and converter motor making this series of laundry equipment more stable and energy-saving, to meet the big capacity need for hotel and hospital,our soft mount type washer extractor can make the 150kg capacity,and all the model are protect by CE certifications..

manual barrier washer extractor unit easy use for laundry plants 14
NO.1 / Stainless steel inner drum
High quality #304 stainless steel material is for anti-rust and long-term service.
manual barrier washer extractor unit easy use for laundry plants 15
NO.2 / Computer controller for washer
Suitable computer and inverter to control the machine .Has advantage of energy saving and stable running.have passed CE certification.
manual barrier washer extractor unit easy use for laundry plants 16
NO.3 / Imported door seal rubber
The high quality seal ring is installed at the outer of water liquid.
manual barrier washer extractor unit easy use for laundry plants 17
NO.4 / Manual detergent design
Manual detergent supply or automatic dosing supply can be ordered to produce.
manual barrier washer extractor unit easy use for laundry plants 18
NO.5 / Motor
For soft mount models ,adopt the international advanced suspension structure and strong motor which with strong spring and hydraulic pressure to absorb the shock,supply the power what the machine need .
manual barrier washer extractor unit easy use for laundry plants 19
NO.6 / Steam value
Above 80kg washer are steam heating,durable pneumatic fill valve and steam value which control by computer to work automatic.



PACKING & SHIPPING

manual barrier washer extractor unit easy use for laundry plants 20

We support both OEM & ODM packaging. Our normally delivery method are by the  sea, by air, by international express (DHL, UPS, TNT, FedEx)



Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
