Model | XGQ-50FB | XGQ-35FB(FBD) | XGQ-25FB(FBD) | CX15(D) | CX12(D) | CX10(D) | CX08(D) | ||
Capacity | kg | 50 | 35 | 25 | 15 | 12 | 10 | 8 | |
Drum size(Φ×L) | mm | Φ955×700 | Φ955×490 | Φ750×540 | 670x425 | 580x460 | 580x380 | 580x310 | |
Washing speed | r/min | 36 | 36 | 38 | 38 | 45 | 45 | 45 | |
Extract speed | r/min | 680 | 680 | 750 | 540 | 530 | 530 | 530 | |
Motor power/ Heat power | kw | 7.5/36 | 5.5/27 | 3/21 | 2.2/15 | 1.5/12 | 1.5/9 | 1.1/7.5 | |
Weight | kg | 1100 | 960 | 550 | 500 | 300 | 280 | 260 | |
External Size | Length | mm | 1200 | 1200 | 990 | 820 | 750 | 750 | 750 |
Width | mm | 1480 | 1310 | 1240 | 1030 | 1130 | 1050 | 980 | |
Height | mm | 1700 | 1700 | 1360 | 1270 | 1100 | 1100 | 1100 |
Workshop Products
◆ Imported bearing, precise and durable.
◆ Fully automatic, microcomputer-controlled.
◆ #304 Stainless steel cabinet and drum.
◆ Multiple sealing system, oil sealing, water sealing, stainless steel sealing.
◆ Microprocessor, freely programmable, 6 standard programs,30 possible programs.
Products Details
8kg-50kg hard mount industrial washing machine is a series of laundry machine under the GOWORLD brand.It has the characteristics of continuum-style bearing housing structure and computer control system,the bearing is imported from Japan,which have 2years warranty, it’s especially suitable for medical unit laundry machine,Inn laundry machine,clinic laundry machine and railway company laundry machine, etc.the use of high-powered motor and inverter control makes these series of laundry machine more stable and energy-saving,and reach the industrial washing machine tumble washer standard, all the models are protect by CE certifications.
PACKING & SHIPPING
We support both OEM & ODM packaging. Our normally delivery method are by the sea, by air, by international express (DHL, UPS, TNT, FedEx)
industrial washer extractor, laundry machine, washer extractor laundry equipment, laundry washing machine
This automatic laundry machine is your ideal equipment for hotels, hospitals, restaurants, army, dyeing industrial and schools to wash clothes of cotton and woolen. Easy operation and maintenance, durable in use. Laundry washing equipment include washer extractor, dry cleaning machine, dryer, ironing machine, spotting table etc.
Models | XGQ-30 | XGQ-50 | XGQ-70 | XGQ-100 | XGQ-120 | XGQ-150 | ||
Power Voltage (V) | 380 | 380 | 380 | 380 | 380 | 380 | ||
Motor power (Kw) | 4 | 5.5 | 5.5/7.5 | 7.5 | 11 | 15 | ||
Power requirement (kw) | 20 | 30 | 30 | 30 | 40 | 60 | ||
Cooling water inlet | Pipe thread | 11/2 | 11/2 | 11/2 | 2 | 2 | 2 | |
mm | 48.054 | 48.054 | 48.054 | 60.092 | 60.092 | 60.092 | ||
Steam inlet | Pipe thread | 1 | 1 | 1 | 1 | 1 | 11/2 | |
mm | 33.28 | 33.28 | 33.28 | 33.28 | 33.28 | 48.054 | ||
Power consumption for one complete wash session with steam heating (kw/h) | 0.9 | 1 | 1.6 | 1.8 | 2.0 | 2.2 | ||
Power consumption for one complete wash session with electric heating (kw/h) | 6 | 7 | 13 | 15 | 17 | 19 | ||
Required water supply pressure(mpa) | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | ||
Water consumption for one complete wash session (L) | 550 | 750 | 1100 | 1800 | 1900 | 2500 | ||
Required steam pressure (mpa) | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | ||
Steam consumption for one complete wash session (kg) | 25 | 30 | 45 | 50 | 60 | 70 | ||
Required pneumatic pressure (mpa) | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | ||
Machine Dimension (mm) | Length | 1600 | 1600 | 1600 | 1950 | 1950 | 1950 | |
Width | 1580 | 1780 | 1940 | 2000 | 2200 | 2600 | ||
Height | 1950 | 2050 | 2050 | 2300 | 2300 | 2300 | ||
Machine Weight (KG) | 2000 | 2500 | 3000 | 4000 | 4500 | 5500 |
