Folding Machine laumdry machine
Foshan Goworld Laundry Equipment CO.,Ltd was built in 1990year. It is a famous company of “GOWORLD”laundry equipment in Zhujiang Delta which is a Developed industry area. Its factory is about 15000m2. It is major in producing a series of washing machine, drying machine dry-cleaning machine, ironing equipments.
Folding Machine
Model | Unit | Z3200-V | |
Max.Folding Length | mm | 3300 | |
Max.Folding Width | mm | 3200 | |
Working Capacity | m/min | 35 | |
Air Pressure | Mpa | 0.6-0.7 | |
Compressed Air Consumption | L/min | 90 | |
Total Power | Kw | 2 | |
Net Weingt | kg | 1800 | |
Size | Length | mm | 3723 |
Width | mm | 2950 | |
Height | mm | 1990 | |
1. With static electricity elimination device.
2. With safety switch to ensure the operation safely.
3. Adopt big screen and intelligent control system .Chinese and English display for choice.
4. It is available to folding in two channels. This can improve the ironing and folding efficiency for small material and low down the energy consumption.
5. All the control valves are pneumatic controlled to ensure the quick and steady actions .
6. Adopt the intelligent infrared testing system.
7. It has function of automatic diagnosis; protect safety system, and self-maintenance for testing points.
